Specifications:
Item/Model | LMC4-400 | LMC4-600 | LMC4-800 | LMC4-1000 |
Coil Width(mm) | 70-400 | 70-600 | 70-800 | 70-1000 |
Coil Thickness(mm) | 0.6-6.0 | 0.6-6.0 | 0.6-6.0 | 0.6-6.0 |
Coil Inside Diameter (mm) | 508 | 508 | 508 | 508 |
Coil Outside Diameter (mm) | 1400 | 1400 | 1400 | 1400 |
Coil Load(kg) | 4000 | 5000 | 5000 | 7000 |
Feeding Speed | 16m/min | 16m/min | 16m/min | 16m/min |
Straightening Roller | Upper4 Lower3 | Upper4 Lower3 | Upper4 Lower3 | Upper4 Lower3 |
Feeding Roller | Upper1 Lower1 | Upper1 Lower1 | Upper1 Lower1 | Upper1 Lower1 |
Main Motor | AC4.4KW | AC5.5KW | AC7.5KW | AC7.5KW |
Decoil Expansion | Hydraulic | Hydraulic | Hydraulic | Hydraulic |
Decoil Motor | 3.7KW | 3.7KW | 3.7KW | 5.5KW |
Straightening Performance:
Coil Thickness(mm) | LMC4-400 | LMC4-600 | LMC4-800 | LMC4-1000 |
0.6-1.3 | 400 | 600 | 800 | 1000 |
2.0 | 400 | 600 | 800 | 1000 |
2.3 | 400 | 600 | 800 | 1000 |
2.5 | 400 | 600 | 800 | 1000 |
2.8 | 400 | 600 | 800 | 933 |
3.2 | 400 | 600 | 714 | 714 |
4.0 | 400 | 457 | 457 | 457 |
4.5 | 361 | 361 | 361 | 361 |
5.0 | 293 | 293 | 293 | 293 |
6.0 | 203 | 203 | 203 | 203 |
The above figures are the material with yield strength of 392N/m㎡ Max
